3-13
ELECTRICAL TROUBLESHOOTING GUIDE
4. AMP PROTECTION
“S-PROTEC” appears on the FLD.
OK.
Replace IC701.
12 V: CHECK Q701 Part.
32 V: CHECK SMPS Part.
Replace TI AMP IC(IC701, IC702)
Power on.
After unplug power cord, connect again.
“Goodbye”
Display, automatic standby
Is the IC701 pin16, 17
“LOW” signal(0 V)?
Is the AMP IC Power
12 V, 32 V normal?
NO
NO
NO
YES
YES
YES
YES
YES
YES
25
27
