LG SPK5B-W Service Manual

3-2
Copyright © 2018 LG Electronics Inc. All rights reserved.
Only for training and service purposes.
TOP
FFC
Harness
Bottom
T
OP
FF
C
H
H
a
r
n
e
s
s
B
o
tt
o
m
Download Connector
B
MTK Download 㟝 4 P, 2 mm , ST, Non_Lock, SMD (6630R3S006L) MICOM Download 㟝 4 P, 1 mm , ST, Non Lock, SMD (6630R- FB02D)
B to B
KEY
FRONT
HDMI
PTB
OPT
ADAPTER
HDMI
4 P, 2.0 mm
ST, Lock, SMD
5 P, 2.0 mm
ST, Lock, SMD
USB
MAIN
Wi-Fi
LCD Module
2 P, 1.25 mm
ST, Non_Lock ,
SMD
6 P, 1.25 mm
ST, Non_Lock , SMD
10 P, 1 mm
AG, Lock, SMD
12 P, 2 mm
ST, SOCKET,
SMD
Ethernet
U
12 P, 0.5 mm
AG, Lock , SMD
12 P, 2 mm
AG, HEADER, SMD
BT
B
26 P, 0.5 mm
AG, Lock , SMD
Wireless
WIRING DIAGRAM
