22 Input select (Command: x b) (Main Picture Input)
► To select input source for main picture.
Transmission
(x)(b)( )(Set ID)( )(Data)(Cr)
Data Structure
MSB LSB
0 0 0 0 0 0 0 0
External Input Input Number
External Input Data
0 0 0 0 DTV
0 0 0 1 Analogue
0 0 1 0 AV
0 1 0 0 Component
0 1 1 0 RGB
0 1 1 1
HDMI
1 0 0 0
1 0 0 1
1 0 1 0
Input Number Data
0 0 0 0 Input1
0 0 0 1 Input2
0 0 1 0 Input3
0 0 1 1 Input4
Ack
(b)( )(Set ID)( )(OK/NG)(Data)(x)
23 Programme block/unblock (Command: m d)
► This command may work differently depending on model and signal.
(For South Korea, North/Latin America except Colombia Model)
Transmission
(m)(d)( )(Set ID)( )(Data 00)( )(Data 01)( )(Data 02)(Data 03)(Data 04)()
(Data 05)( )(Data 06)(Cr)
(Data 00) : Physical Channel Number
(Data 01)(Data 02) : Major Channel Number
- (Data 01) : High Channel data
- (Data 02) : Low Channel data
00 00 ~ 27 0F (Decimal : 0 ~ 9999)
(Data 03)(Data 04) : Minor Channel Number
- (Data 03) : High Channel data
- (Data 04) : Low Channel data
(Data 05) : Input Source
- 02 : Antenna TV (DTV)
- 06 : Cable TV (CADTV)
- 0b : Cable DTV Plus
(Data 06) : block(01)/unblock(00)
Ack
(d)( )(Set ID)( )(OK/NG)(Data 00)(Data 01)(Data 02)(Data 03)(Data 04)
(Data 05)(Data 06)(x)
* Block/Unblock Command Examples
Block/Unblock Cable DTV (DVB-T) Channel 18-2
(Set ID) = 01
(Data 00) = Physical Channel Number 18 = 12(HEX)
(Data 01) & (Data 02) = Major Channel Number is 18 = 00 12(HEX)
(Data 03) & (Data 04) = Major Channel Number is 2 = 00 02(HEX)
(Data 05) = cable DTV = 06
(Data 06) = block(01)/unblock(00)
Result :
md 01 12 00 12 00 02 06 (01/00)
