Outdoor Units
❈ Target frequency step (Step_base) exceeds maximum step, the Step_base value follows the maximum step
value.
❈ The compressor get the minimum step in case Step_base value is lower than the minimum step of operating
capacity.
Compressor operation range
Control
Capacity
Load
Inv.
Inv.
Inv.
Const.
Const.1
Const.2
1 comp.
model
2 comp.
model
3 comp.
model
Inv. Inv. Inv. C C1
C2
