LG Universal System Air Conditioner - Parts List

Exploded View & Replacement Parts List
162 Universal System Air Conditioner
263230-1 THERMISTOR ASEEMBLY (INDOOR INLET) 6323AQ3214E 6323AQ3214E R
263230-2 THERMISTOR ASEEMBLY (PIPE INLET) 6323AQ3226V 6323AQ3226V R
263230-3 THERMISTOR ASEEMBLY (PIPE OUTLET) 6323AQ3226E 6323AQ3226E R
336610-1 HOUSING (MECH),WRAPPER 3660A20017A 3660A20017A R
336610-2 HOUSING (MECH),WRAPPER 3660A20018A 3660A20018A R
346810 MOTOR ASSEMBLY,INDOOR 4681A10013C 4681A10013C R
359012-1 FAN ASSEMBLY,BLOWER 5901A10026A 5901A10026A R
359012-2 FAN ASSEMBLY,BLOWER 5901A10028B 5901A10028B R
W0CZZ CAPACITOR,DRAWING 2A00986D 2A00986D R
354210 EVAPORATOR ASSEMBLY,FIRST 5421A10027A 5421A20100B R
352118 TUBE ASSEMBLY,MENIFOLD(INDOOR) 5211A20416J 5211A20465G R
552111 TUBE ASSEMBLY,CAPILLARY 5211A20693E 5211A20466N R
330870 DRAIN PAN ASSEMBLY 3087A10008B 3087A10008B R
249951 CONTROL BOX ASSEMBLY,INDOOR 4995A14002E 4995A14002F R
268714 PWB(PCB) ASSEMBLY,MAIN 6871A10140X 6871A10140Y R
267110-2 REMOTE CONTROLLER ASSEMBLY 6711A10008D 6711A10008D R
152302 FILTER(MECH),A/C 5230A30001M 5230A30001M R
ABNH186HLAB
[UB18 NHB]
ABNH246HLAB
[UB24 NHB]
LOCATION
No.
DESCRIPTION
Part No.
SVC CODE
Parts List
