Exploded View & Replacement Parts List
178 Universal System Air Conditioner
137213 PANEL ASSEMBLY,SIDE 3721A10120A 3721A10120A R
567480-1
THERMISTOR ASSEMBLY(INV. D-PIPE & S-PIPE SENSOR)
6323A20020L 6323A20020L R
567480-2
THERMISTOR ASSEMBLY(CONDENSOR & AIR SENSOR)
6323A20020K 6323A20020K R
263230-1
THERMISTOR ASSEMBLY (CONSTANT D-PIPE SENSOR)
6323A20001Q 6323A20001Q R
263230-2
THERMISTOR ASSEMBLY (CONSTANT D-PIPE SENSOR)
6323A20001R 6323A20001R R
330870 DRAIN PAN ASSEMBLY 3087A10023C 3087A10023C R
346811 MOTOR ASSEMBLY,SINGLE 4681A20155B 4681A20155B R
352112 TUBE ASSEMBLY,COUPLING 5211A10284D 5211A10284D R
352114 TUBE ASSEMBLY,DISTRIBUTOR 5211A21190B 5211A21190B R
430410 BASE ASSEMBLY,OUTDOOR 3041A10058C, B 3041A10058C R
435310 GRILLE ASSEMBLY,FRONT(OUTDOOR) 3531A10266D 3531A10266D R
435301 GRILLE,DISCHARGE 3530A20117A 3530A20117A R
435512 COVER ASSEMBLY,TOP(OUTDOOR) 3551A10062A 3551A10062A R
437211 PANEL ASSEMBLY,FRONT(OUTDOOR) 3721A10107B 3721A10107B R
447910-1 BARRIER ASSEMBLY,OUTDOOR 4791A10022A 4791A10022A R
447910-2 BARRIER ASSEMBLY,OUTDOOR 4791A20035A 4791A20035A R
55211E TUBE ASSEMBLY,CHECK VALVE 5211A23023C 5211A23023B R
546810 MOTOR ASSEMBLY,OUTDOOR 4681A10014H 4681A10014H R
548490-1 ACCUMULATOR ASSEMBLY(MECH) 4849A10003F 4849A10003F R
548490-2 ACCUMULATOR ASSEMBLY(MECH) 4849A10041D, E 4849A10041D R
549610 MOUNT ASSEMBLY,MOTOR(OUTDOOR) 4961A20028B 4961A20028B R
552112-1 TUBE ASSEMBLY,CONDENSER IN 5211A10480A 5211A10480A R
552112-2 TUBE ASSEMBLY,CONDENSER IN 5211A10480B 5211A10480B R
552112-3 TUBE ASSEMBLY,CONDENSER IN 5211A10480E 5211A10480E R
552112-4 TUBE ASSEMBLY,CONDENSER IN 5211A10480F 5211A10480F R
552113-1 TUBE ASSEMBLY,CONDENSER OUT 5211A10481A 5211A10481A R
552113-2 TUBE ASSEMBLY,CONDENSER OUT 5211A10481B 5211A10481B R
552116 TUBE ASSEMBLY,REVERSING 5211A21324C 5211A21324C R
55211G TUBE ASSEMBLY,EXPANSION 5211A11049A 5211A11049A R
552203-1 VALVE,SERVICE 2A00499N 2A00499N R
552203-2 VALVE,SERVICE 5220A20001J 5220A20001J R
554030-1 CONDENSER ASSEMBLY,FIRST 5403A21003E 5403A21003E R
554030-2 CONDENSER ASSEMBLY,FIRST 5403A21003F 5403A21003F R
554030-3 CONDENSER ASSEMBLY,FIRST 5403A21003G 5403A21003G R
554030-4 CONDENSER ASSEMBLY,FIRST 5403A21003H 5403A21003H R
554160-1 COMPRESSOR(INVERTER) 5416A90015A 5416A90015A R
554160-2 COMPRESSOR(CONSTANT) 5416A90021A 5416A90021A R
554160-3 COMPRESSOR(CONSTANT) 5416A90021A 5416A90017A R
558511 DRIER ASSEMBLY 5851A20002A 5851A20002A R
559010 FAN ASSEMBLY,PROPELLER 5901A10029A 5901A10029A R
561410-1 COIL ASSEMBLY,REVERSING VALVE 6141A20013W 6141A20013W R
561410-2 COIL ASSEMBLY,REVERSING VALVE 6141A20024A 6141A20024A R
661400 COIL ASSEMBLY,EXPANSION 6141A30003P 6141A30003P R
649950 CONTROL BOX ASSEMBLY,OUTDOOR 4995A10145F, E 4995A10145F R
261704 REACTOR 5874A90006A 5874A90006A R
268711-6 PWB(PCB) ASSEMBLY,MAIN(OUTDOOR) 6871A10117W 6871A10117X R
WOCZZ-1 CAPACITOR,DRAWING 2A00986Y 2A00986Y R
WOCZZ-2 CAPACITOR,DRAWING 2A00986C 2A00986C R
WOCZZ-3 CAPACITOR,DRAWING - 2A00986A R
435312 GRILL ASSEMBLY REAR(OUTDOOR) 3721A10108B 3721A10108B R
AUUW4860
[UU48 WUYB]
AUUW6060
[UU60 WUYB]
LOCATION
No.
DESCRIPTION
Part No.
SVC CODE
Parts List
