7-1.BEFORE PERFORMING SERVICE
󰳪 Be careful of electric shock or disconnecting the parts while trouble shooting.
󰳪 Voltage of each terminal in 220-240V and DC while applying an electric current.
7-2.QC TEST MODE.
󰾂
Pressing
Pre Wash and Crease Care
button simultaneously.
󰾃
Power button ON with pressing upper two button. then buzzer sound twice.
󰾄
Press the START / PAUSE button as follows.
[Press the START / PAUSE button more 4 times until stop spinning]
7-3.HOW TO KNOW THE WATER LEVEL FREQUENCY
󱌃 Press the
Bio and Time delay button simultaneously.
ex) 241 : Water level frequency = 241× 10
-1
kHz
= 24.1kHz
13
7. TROUBLESHOOTING
The digits means water level frequency (10
-1
kHz)
Checking Point Display Status
None All lamps turn on
1 timeClockwise spin (lef) Motor rpm (About 50)
2 times Low speed Spin Motor rpm (About 63~67)
3 timesHigh speed SpinMotor rpm (About 79~85) : WD-6515(0~9)T(U)P
WD-8015(0~9)S(N)(T)(U)P
Motor rpm (About 95~106) : WD-9015(0~9)T(U)P
WD-1015(0~9)S(N)(T)(U)P
4 timesInlet valve for pre-wash operationWater level frequency (225~265)
5 times
Inlet valve for main-wash operation
Water level frequency (225~265)
Hot inlet valve in case of hot water fill
6 times Inlet valve for main-wash operation Water level frequency (225~265)
7 time
sCounterclockwise spin (right)Motor rpm (About 50)
8 times A Heater is in operation for 3 sec. Water Temperature
9 times Draining pump operation Water level frequency
10 times Auto off operation
Pressing number of
[START / PAUSE] button
