27
Take apart the cabinet gasket clamp.
Unscrew 2 screws from the cabinet cover.
Open the lower cover cap and unscrew 1 screw inside.
Take apart the lower cover.
Disassemble the cantrol panel. (refer to the 25page)
Unscrew all the screws on the upper and lower sides
of the cabinet cover.
Take apart the tub gasket clamp.
Make sure that the drain hole of the gasket is put
beneath when reassembling the gasket.
Refer to the arrow mark on the tub cover.
GASKET ASSEMBLY
