31
NO
Is the door closed?
Is the Door assembly in line with door switch ?
Lift up & close the door.
If the dE is displayed, replace the Door Bracket.
Close the door fully.
Reconnect or repair the Connector.
Or replace the Harness.
NO
NO
Replace the Spring.
NO
Replace the Door switch.
NO
Does the Spring of Latch Hook actuate?
dE (Door Open Error)
YES
YES
YES
YES
Scratch by Latch Hook
Touching
or
Is the Connector connected correctly to
the Main PCB and the Door Switch?
Is the Harness right?
Does the Door Switch operate as follows?
* Door locking time : 1~8 sec.
Check the time from power on
to the time to door locking.
*
Door releasing time : 25~100 sec.
Check the time from power off to
door releasing.
To Next Page
