LG WT1101CW Service Manual

16
3-3. FUNCTION OF EACH BUTTON
· Select to select Wash
Temperature.
· Pressing the button allows
The selection of TAP COLD
▶COLD ▶ECO WARM
▶WARM▶HOT respectively.
Default setting is Warm.
Wash / Temp.
Note
The time shown on the display is the estimated cycle time. If the sensors and microprocessor elect to
make changes during the cycle, the display will be adjusted accordingly.
Load Sensing
·It operates in all cycles.
· During being detected by the sensor, the
LOADSENSING LED flashes.
·It automatically sensing the size of the load.
· During this step, the washing machine selects
an optimized washing algorithm.
Soil Level
· Allows a selection to be make for the
strength of the wash action.
· Power option selections light up in
sequence as follows Normal ▶ Heavy
▶ Light ▶ Normal as the button is
pushed.
This can be selected for any program.
· Adjustment can be made while
washing.
· Default SOIL LEVEL is Normal.
Spin Speed
· Spin speed
can be
selected from
No Spin to
Extra high.
Default is
High.

LG WT1101CW Specifications

General

Style	Top-Loading
Color	White
Washer Capacity	4.1 cu ft
Dryer Capactity	-
Max Spin Speed	1100 RPM
Spin Speeds	No Spin)
Spin Class	C
Number of Cycles	8
Cycle Selections	Soak
Wash	Quick Wash
Options	prewash
No spin and No heat	Child lock (With LED)
Hours	My Cycle
Noise level	-
Temperature Selections	Cool)
Internal Heater	no
Control Panel	electronic
Delay Start / End	yes
Child Lock	yes
Cycle Signal	yes
Steam	no
Energy Class	-
Annual Energy Consumption	-
Annual Water Consumption	-
Water Consumption Per Cycle	-
Voltage	120 V
Frequency	-
Current	10 A

Weight and Dimensions

Depth	28-3/8 in
Height	40-5/32 in
Width	27 in
Net Weight	132 lbs
