LG WT1101CW Service Manual

5. COMPONENT TESTING INFORMATION
5-1. Filter Assembly (Line Filter)
40
When resistance (Ohm) checking the component, be sure to turn the power off, and do
voltage discharge sufficiently.
Wiring
diagram
Test
points
and
Result
Circuit in the MAIN PCB / Wiring Diagram
MAIN PCB
ASSEMBLY
3 3
1 1
RD1
WH1
Vac
1 1
2 2
2 2
Test Points
WH (1) to RD (1)
WH (3) to RD (2)
Result
0 Ω
0 Ω
(1)
(3)
(1)(2)
RD1
WH1
WARNING

LG WT1101CW Specifications

General

Style	Top-Loading
Color	White
Washer Capacity	4.1 cu ft
Dryer Capactity	-
Max Spin Speed	1100 RPM
Spin Speeds	No Spin)
Spin Class	C
Number of Cycles	8
Cycle Selections	Soak
Wash	Quick Wash
Options	prewash
No spin and No heat	Child lock (With LED)
Hours	My Cycle
Noise level	-
Temperature Selections	Cool)
Internal Heater	no
Control Panel	electronic
Delay Start / End	yes
Child Lock	yes
Cycle Signal	yes
Steam	no
Energy Class	-
Annual Energy Consumption	-
Annual Water Consumption	-
Water Consumption Per Cycle	-
Voltage	120 V
Frequency	-
Current	10 A

Weight and Dimensions

Depth	28-3/8 in
Height	40-5/32 in
Width	27 in
Net Weight	132 lbs
