LG WT1101CW Service Manual

8
3. OPERATING INSTRUCTION
3-1. IDENTIFICATION OF PARTS
POWDER DETERGENT
BOX for delayed
washing/softener additves box
INLET HOLE FOR
BLEACH
WASHING WING
(unique with lnner Tub)
LEVELLING LEGS
Use to level the washing
machine for correct balance
spin operation.
TUB
COLD WATER SUPPLY
HOSE
HOT WATER SUPPLY
HOSE
Make sure the water
does not leak.
POWER PLUG
If the supply cord is
damaged, it must be
replaced by the
manufacturer or its service
agents or similarly
qualified person in order
to avoid a hazard.
HARDENED GLASS
DOOR
DRAIN HOSE
Be sure the drain hose
is properly installed on
the drain before
operating the washer.
SMART RINSE WITH
JET SPRAY
This washer is designed to
save rinse water by using a
jet spray rinse system in the
Normal/Casual and Heavy
Duty cycles.

LG WT1101CW Specifications

General

Style	Top-Loading
Color	White
Washer Capacity	4.1 cu ft
Dryer Capactity	-
Max Spin Speed	1100 RPM
Spin Speeds	No Spin)
Spin Class	C
Number of Cycles	8
Cycle Selections	Soak
Wash	Quick Wash
Options	prewash
No spin and No heat	Child lock (With LED)
Hours	My Cycle
Noise level	-
Temperature Selections	Cool)
Internal Heater	no
Control Panel	electronic
Delay Start / End	yes
Child Lock	yes
Cycle Signal	yes
Steam	no
Energy Class	-
Annual Energy Consumption	-
Annual Water Consumption	-
Water Consumption Per Cycle	-
Voltage	120 V
Frequency	-
Current	10 A

Weight and Dimensions

Depth	28-3/8 in
Height	40-5/32 in
Width	27 in
Net Weight	132 lbs
