LG WT1201CW Service Manual

1. SPECIFICATIONS
3
Model WT1201CW / WT1101CW WT1201CV
Electrical 120 VAC@60 Hz.
Inner Tub Blue White Stainless
Inlet Water Pressure 14.5 ~ 116 PSI (100 ~ 800 kPa)
Rating of Fuse 120V/60Hz
Spin Speed 1100±50 rpm
Weight
134 lbs. (61 kg) [ WT1101C* 132 lbs. (60 kg) ]
Cycles
Cotton/Normal, Heavy Duty, Bright Whites,
Bulky/Bedding, Speed Wash, Pure Color, Delicates, Tub Clean
Time Delay 1 – 19 Hr
Lid Interlock Switch Magnet Sensor
Control Lock Yes
Softener Dispenser Yes
Detergent Dispenser Yes
Bleach Inlet Yes
Auto Power Off Yes
Smart Rinse™with Jet
Spray
Yes
Heater No

LG WT1201CW Specifications

General

Door hinge	Up
Motor type	Beltless
Control type	Buttons
Display type	LED
Loading type	Top-load
Tub material	Plastic
Drum material	Stainless steel
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Dispenser tray type	3-way
Drum capacity	- kg
Delay start (max)	19 h
Spin-drying class	-
Maximum spin speed	1100 RPM
Noise level (wash)	- dB
Number of washing programs	8
Current	10 A
AC input voltage	120 V
Energy consumption washing per cycle	- kWh
Sustainability certificates	ENERGY STAR
Package depth	787 mm
Package width	736 mm
Package height	1092 mm
Package weight	68492.4 g

Weight and Dimensions

Depth	711 mm
Width	685 mm
Height	1016 mm
Weight	60781.3 g
