LG WT1201CW Service Manual

Water tap
Rubber Seal
Water Supply Hose
1
Be sure there is a gasket in both ends of the hose.
Push the water supply hose up so that the rubber packing
within the hose can adhere completely to the tap.
2
Connect the water supply hose to the tap.
Run a couple of gallons of water through the hoses into the drain or a
bucket to flush any particulate or contaminate.
3
Check water leakage.
After connecting the hose, open the tap to check for
any water leakage.
Connecting Water Supply Hose to the Machine
• Be sure there is a gasket in the end of the hose.
• Connect the hose to the appropriate inlet vale
(hot or cold) of the washing machine and tighten if
firmly.
• Turn on the water and check for leacks.
• Always install new hoses with a new washing
machine Do not re-use old hoses.
• Relplace the hoses every five years.
Screw Type
2-2. CONNECTING WATER SUPPLY HOSE
6
Before connecting the water supply hose to the water tap, check the hose type and then choose the
correct instruction here below.

LG WT1201CW Specifications

General

Door hinge	Up
Motor type	Beltless
Control type	Buttons
Display type	LED
Loading type	Top-load
Tub material	Plastic
Drum material	Stainless steel
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Dispenser tray type	3-way
Drum capacity	- kg
Delay start (max)	19 h
Spin-drying class	-
Maximum spin speed	1100 RPM
Noise level (wash)	- dB
Number of washing programs	8
Current	10 A
AC input voltage	120 V
Energy consumption washing per cycle	- kWh
Sustainability certificates	ENERGY STAR
Package depth	787 mm
Package width	736 mm
Package height	1092 mm
Package weight	68492.4 g

Weight and Dimensions

Depth	711 mm
Width	685 mm
Height	1016 mm
Weight	60781.3 g
