LG WT1201CW Service Manual

5
26.8″
(68.0 cm)
4.7″
(12.0 cm)
54.33″
(138.0 cm)
(with lid
open)
27.4″
(69.6 cm)
0.8″
(2.0 cm)
0.8″
(2.0 cm)
40.16″
(102.0 cm)
6
75
Confirming level
• Place the washer in original position,
confirming the level.
Horizontal setting
• If the washer is not level, adjust the
leveling feet. Turn clockwise to raise,
counterclockwise to lower.
Distance between the drain hose
and the wall
• Distance between the drain hose and
the wall should be more than 4 inches
(10 cm,) and the distance between any
other part and the wall should be more
than 1 inches (2.5 cm.)
Do not install the washer in the following places.
• Where the washer is exposed to direct sunlight.
• Near a heater or heating appliance.
• Where the washer is exposed to freezing temperatures.
• In damp environments such as bathrooms or harmful environments.
Lower
Raise
side to side
front to back

LG WT1201CW Specifications

General

Door hinge	Up
Motor type	Beltless
Control type	Buttons
Display type	LED
Loading type	Top-load
Tub material	Plastic
Drum material	Stainless steel
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Dispenser tray type	3-way
Drum capacity	- kg
Delay start (max)	19 h
Spin-drying class	-
Maximum spin speed	1100 RPM
Noise level (wash)	- dB
Number of washing programs	8
Current	10 A
AC input voltage	120 V
Energy consumption washing per cycle	- kWh
Sustainability certificates	ENERGY STAR
Package depth	787 mm
Package width	736 mm
Package height	1092 mm
Package weight	68492.4 g

Weight and Dimensions

Depth	711 mm
Width	685 mm
Height	1016 mm
Weight	60781.3 g
