LG WT1201CW Service Manual

4
2. INSTALLATION INSTRUCTIONS
2-1. HOW TO ADJUST LEVEL
4
Raise Lower
CAUTION
Raise Lower
CAUTION
Raise Lower
CAUTION
Raise Lower
CAUTION
• The ventilating openings in the base area must not be obstructed by carpeting.
• Install the washing machine on a level and firm surface. There should be no more than 1° of variation.
• Wooden floors may need reinforcing to prevent the normal vibration which occurs
with an unbalanced load.
• Do not install the washer on an inclined floor.
Improper installation of the washer may cause noise and malfunctioning.
1
Installation area
•
Install the washer on a firm, flat
surface.
•
If the washer is installed on an
unsuitable floor, it could make
considerable noise and vibrate.
2
3
Checking level
•
Open the lid, check if the washer is
correctly leveled by looking down
from the top. If the tub is not
centered in the opening, then the
washer is not level.
No shims. It would be dangerous. If the
floor is that far from being level, it is a floor
problem and not a washer problem.
Set Leveling feet
•
Adjust the leveling feet, Turn clockwise
to raise the washer or
counterclockwise to lower it.
Checking slope
•
If installation surface is tilted, the
washer will vibrate. Do not install
on a sloping floor.

LG WT1201CW Specifications

General

Door hinge	Up
Motor type	Beltless
Control type	Buttons
Display type	LED
Loading type	Top-load
Tub material	Plastic
Drum material	Stainless steel
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Dispenser tray type	3-way
Drum capacity	- kg
Delay start (max)	19 h
Spin-drying class	-
Maximum spin speed	1100 RPM
Noise level (wash)	- dB
Number of washing programs	8
Current	10 A
AC input voltage	120 V
Energy consumption washing per cycle	- kWh
Sustainability certificates	ENERGY STAR
Package depth	787 mm
Package width	736 mm
Package height	1092 mm
Package weight	68492.4 g

Weight and Dimensions

Depth	711 mm
Width	685 mm
Height	1016 mm
Weight	60781.3 g
