LG WT1201CW Service Manual

8
3. OPERATING INSTRUCTION
3-1. IDENTIFICATION OF PARTS
POWDER DETERGENT
BOX for delayed
washing/softener additves box
INLET HOLE FOR
BLEACH
WASHING WING
(unique with lnner Tub)
LEVELLING LEGS
Use to level the washing
machine for correct balance
spin operation.
TUB
COLD WATER SUPPLY
HOSE
HOT WATER SUPPLY
HOSE
Make sure the water
does not leak.
POWER PLUG
If the supply cord is
damaged, it must be
replaced by the
manufacturer or its service
agents or similarly
qualified person in order
to avoid a hazard.
HARDENED GLASS
DOOR
DRAIN HOSE
Be sure the drain hose
is properly installed on
the drain before
operating the washer.
SMART RINSE WITH
JET SPRAY
This washer is designed to
save rinse water by using a
jet spray rinse system in the
Normal/Casual and Heavy
Duty cycles.

LG WT1201CW Specifications

General

Door hinge	Up
Motor type	Beltless
Control type	Buttons
Display type	LED
Loading type	Top-load
Tub material	Plastic
Drum material	Stainless steel
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Dispenser tray type	3-way
Drum capacity	- kg
Delay start (max)	19 h
Spin-drying class	-
Maximum spin speed	1100 RPM
Noise level (wash)	- dB
Number of washing programs	8
Current	10 A
AC input voltage	120 V
Energy consumption washing per cycle	- kWh
Sustainability certificates	ENERGY STAR
Package depth	787 mm
Package width	736 mm
Package height	1092 mm
Package weight	68492.4 g

Weight and Dimensions

Depth	711 mm
Width	685 mm
Height	1016 mm
Weight	60781.3 g
