LI-COR 7200-101 - Flow Rate Data Output

Section 1. Overview of the 7200-101 Flow Module
Flow Rate Data Output
Flow variables can be output via the RS-232 and/or Ethernet ports of the LI-7550
Analyzer Interface Unit. The RS-232 and Ethernet tab are used to set the RS-232
and LI-7200/RS Ethernet port configuration(s) for unattended data collection. After
configuration, click Apply; the LI-7200/RS will begin to send data out the RS-232
and/or Ethernet ports according to these parameters. If you are connected via the
port that you have modified, the settings take effect after you Disconnect from the
instrument. If you are connected to the RS-232 port, you can modify the Ethernet
settings and click Apply; the changes take effect immediately, and vice versa.
