Liebert GXT2U - Specifications

Specifications
33
SPECIFICATIONS (CONTINUED)
Model Number GXT2-1500RT120 GXT2-2000RT120 GXT2-3000RT120
Model Rating 1500VA / 1050W 2000VA / 1400W 3000VA / 2100W
DIMENSIONS - in. (mm)
Unit
W x D x H
3.5 x 21.5 x 17
(87 x 547 x 430)
3.5 x 21.5 x 17
(87 x 547 x 430)
3.5 x 24.2 x 17
(87 x 618 x 430)
Shipping
W x D x H
10.6 x 27.2 x 23
(269 x 691 x 584)
10.6 x 27.2 x 23
(269 x 691 x 584)
10.6 x 27.2 x 23
(269 x 691 x 584)
WEIGHT - lb. (kg)
Unit 50.6 (23) 54 (24) 69 (31)
Shipping 59.5 (27) 62.6 (28.4) 78.0 (35.4)
INPUT AC PARAMETERS
Voltage Range (typical) 120 VAC nominal; variable based on output load
100% - 90% loading 90 VAC / 140 VAC 90 VAC / 140 VAC 90 VAC / 140 VAC
90% -70% loading 80 VAC / 140 VAC 80 VAC / 140 VAC 80 VAC / 140 VAC
70% -30% loading 70 VAC / 140 VAC 70 VAC / 140 VAC 70 VAC / 140 VAC
30% - 0% loading 60 VAC / 140 VAC 60 VAC / 140 VAC 60 VAC / 140 VAC
Frequency 40 - 70 Hz; Auto Sensing
Input Power Cord
10 ft. attached
w/ NEMA 5-15 plug
10 ft. attached
w/ NEMA 5-20 plug
10 ft. attached
w/ NEMA L5-30 plug
OUTPUT AC PARAMETERS
Output Receptacles (6) NEMA 5-15R
(6) 5-20R T-Slot,
accepts 15A plug
(6) 5-20R T-Slot
(1) NEMA L5-30R
on 12 in cord
Voltage 100/110/115/120/127 (user configurable) VAC; ±3%
Frequency 50 Hz or 60 Hz
Waveform Sinewave
Main Mode Overload 200% for 8 cycles; 130% for 10 seconds with transfer to bypass
BATTERY PARAMETERS
Type Valve-regulated, nonspillable, lead acid
Qty x V x Rating 4 x 12V x 7.0 or 7.2 AH 4 x 12V x 9.0 AH 6 x 12V x 9.0 AH
Battery Mfg / Part #
China Storage Battery/
CSB 1270 F2
Panasonic / UP-VW1245P1
Yuasa / REW 45-12
Backup Time See 13.0 - Battery Run Times
Recharge Time 5 hours to 95% capacity after full discharge into 100% load
ENVIRONMENTAL
Operating Temp +32°F to +104°F (0°C to +40°C)
Storage Temp +5°F to +122°F (-15°C to +50°C)
Relative Humidity 0% to 95%, non-condensing
Operating Elevation Up to 10,000 ft. (3000m) at 104°F (40°C) without derating
Storage Elevation 50,000 ft. (15,000m) maximum
Audible Noise
<50 dBA, at 1 meter
from the rear
<45 dBA, at 1 meter
from the front or sides
<55 dBA, at 1 meter
from the rear
<50 dBA, at 1 meter
from the front or sides
AGENCY
Safety UL 1778, c-UL Listed
RFI/EMI FCC Part 15, Subpart B, Class A
Surge Immunity IEEE/ANSI C62.41 Category A & B
Transportation ISTA Procedure 1A
DISCONTINUED
PRO DU C T
