Liebert Hiflex - Page 103

Hiflex
99All Versions
English
OVER MODELS
Double circuit
5
SP/O/AW
5
LG/O/AW
7
SP/O/AW
7
LG/O/AW
9
SP/O/AW
9 LG/O/
AWDHF
rows [no.] 1 1 1 1 1 1
front surface [m
2
] 0.44 0.44 0.66 0.66 0.66 0.66
ambient temp. 24C, 50% R.H. water inlet/outlet temperature 80/65C.
power [kW] 13.3 13.7 17.0 16.9 27.1 28.5
water flow [l/s] 0.22 0.22 0.28 0.28 0.45 0.47
coil side pressure drops [kPa] 1 1 1 1 3 3
total pressure drops [kPa] 1 1 2 2 3 4
ambient temp. 20C, 50% R.H. water inlet/outlet temperature 80/65C.
power [kW] 14.2 14.6 18.2 18.0 29.0 30.5
water flow [l/s] 0.23 0.24 0.30 0.30 0.48 0.51
coil side pressure drops [kPa] 1 1 2 1 3 3
total pressure drops [kPa] 2 2 2 2 4 4
NOTE Standard air flow. Available head: Under=20 Pa; Over=30 Pa.
Hot water coil connections ø 18 mm.
(1)
Condensation temperature 45
o
C.
Performances of DX units heating only - 50/60 Hz
UNDER MODELS
Single circuit
4
M/U/A
4
SP/U/AW
4
LG/U/AW
6
SP/U/AW
6
LG/U/AW
8
SP/U/AW
8
LG/U/
AWDHF
rows [no.] 1 1 1 1 1 1 1
front surface [m
2
] 0.22 0.22 0.22 0.33 0.33 0.33 0.33
ambient temp. 24C, 50% R.H. water inlet/outlet temperature 80/65C.
power [kW] 5.6 5.9 7.2 9.1 9.7 12.3 12.9
water flow [l/s] 0.09 0.09 0.12 0.15 0.16 0.20 0.21
coil side pressure drops [kPa] 1 1 1 1 1 2 2
total pressure drops [kPa] 1 1 1 2 2 2 3
ambient temp. 20C, 50% R.H. water inlet/outlet temperature 80/65C.
power [kW] 6.1 6.5 7.9 10.0 10.7 13.6 14.2
water flow [l/s] 0.10 0.10 0.13 0.16 0.17 0.22 0.23
coil side pressure drops [kPa] 1 1 1 1 1 2 2
total pressure drops [kPa] 1 1 2 2 2 3 3
OVER MODELS
Single circuit
4
M/O/A
4
SP/O/AW
4
LG/O/AW
6
SP/O/AW
6
LG/O/AW
8
SP/O/AW
8
LG/O/
AWDHF
rows [no.] 1 1 1 1 1 1 1
front surface [m
2
] 0.22 0.22 0.22 0.33 0.33 0.33 0.33
ambient temp. 24C, 50% R.H. water inlet/outlet temperature 80/65C.
power [kW] 4.8 5.5 6.8 8.8 9.2 11.6 11.8
water flow [l/s] 0.08 0.09 0.11 0.14 0.15 0.19 0.19
coil side pressure drops [kPa] 1 1 1 1 1 2 2
total pressure drops [kPa] 1 1 1 1 2 3 3
ambient temp. 20C, 50% R.H. water inlet/outlet temperature 80/65C.
power [kW] 5.3 6.0 7.5 9.7 10.1 12.8 13.0
water flow [l/s] 0.08 0.10 0.12 0.16 0.16 0.21 0.21
coil side pressure drops [kPa] 1 1 1 1 1 2 3
total pressure drops [kPa] 1 1 2 2 2 3 3
