Liebert Hiflex - Page 104

Hiflex
100 All Versions
English
UNDER MODELS
Double circuit
5
SP/U/AW
5
LG/U/AW
7
SP/U/AW
7
LG/U/AW
9
SP/U/AW
9
LG/U/
AWDHF
rows [no.] 1 1 1 1 1 1
front surface [m
2
] 0.44 0.44 0.66 0.66 0.66 0.66
ambient temp. 24C, 50% R.H. water inlet/outlet temperature 80/65C.
power [kW] 11.7 14.3 18.2 19.3 24.5 25.7
water flow [l/s] 0.19 0.23 0.30 0.32 0.41 0.43
coil side pressure drops [kPa] 1 1 2 2 2 2
total pressure drops [kPa] 1 2 2 2 3 3
ambient temp. 20C, 50% R.H. water inlet/outlet temperature 80/65C.
power [kW] 12.8 15.8 20.0 21.2 27.0 28.2
water flow [l/s] 0.21 0.26 0.33 0.35 0.45 0.47
coil side pressure drops [kPa] 1 2 2 2 3 3
total pressure drops [kPa] 1 2 2 2 3 4
OVER MODELS
Double circuit
5
SP/O/AW
5
LG/O/AW
7
SP/O/AW
7
LG/O/AW
9
SP/O/AW
9 LG/O/
AWDHF
rows [no.] 1 1 1 1 1 1
front surface [m
2
] 0.44 0.44 0.66 0.66 0.66 0.66
ambient temp. 24C, 50% R.H. water inlet/outlet temperature 80/65C.
power [kW] 10.9 13.6 17.5 18.3 21.9 23.4
water flow [l/s] 0.18 0.22 0.29 0.30 0.36 0.39
coil side pressure drops [kPa] 1 1 1 2 2 2
total pressure drops [kPa] 1 1 2 2 3 3
ambient temp. 20C, 50% R.H. water inlet/outlet temperature 80/65C.
power [kW] 12.1 15.0 19.3 20.1 24.1 25.8
water flow [l/s] 0.20 0.25 0.32 0.33 0.40 0.43
coil side pressure drops [kPa] 1 1 2 2 2 2
total pressure drops [kPa] 1 2 2 2 3 3
NOTE Standard air flow. Available head: Under=20 Pa; Over=30 Pa.
Hot water coil connections ø 18 mm.
