Liebert Hiflex - Water Condenser and Dry Cooler Specifications

Hiflex
15All Versions
English
Performances Electric data Overall dimensions
Low noise
Model
Duty (
d
) Air flow
SPL 5 m
Supply
Number of
fans
Total
absorbed
power
Width Depth
Height
(
c
)
kW m
3
/h db(A) V/ph/Hz nº kW mm mm mm
HCA07 5.0 1230 38 230/1/50(
a
) 1 0.16 803 451 703
HCA10 7.2 2750 41 230/1/50(
a
) 2 0.32 1253 451 703
HCA14 11.1 3230 40 230/1/50(
a
) 1 0.20 1175 797 890
HCA17 12.7 2920 40 230/1/50(
a
) 1 0.20 1175 797 890
HCA24 20.4 6260 45 230/1/50(
b
) 1 0.37 1325 1098 992
HCA29 23.6 5950 45 230/1/50(
b
) 1 0.37 1325 1098 992
HCA33 25 5840 43 230/1/50(
a
) 2 0.39 2125 797 890
HBA33 25 5840 43 230/1/50(
a
) 2 0.39 2125 797 890
HCA42 36.4 12520 48 230/1/50(
b
) 2 0.74 2425 1098 992
HCA49 40.8 12520 48 230/1/50(
b
) 2 0.74 2425 1098 992
HBA49 40.8 12520 48 230/1/50(
b
) 2 0.74 2425 1098 992
HCA58 47.2 11900 48 230/1/50(
b
) 2 0.74 2425 1098 992
HCA74 61.2 18780 51 230/1/50(
b
) 3 1.11 3526 1098 992
HBA74 61.2 18780 51 230/1/50(
b
) 3 1.11 3526 1098 992
HCA87 70.8 17850 51 230/1/50(
b
) 3 1.11 3526 1098 992
HBA87 70.8 17850 51 230/1/50(
b
) 3 1.11 3526 1098 992
HCA95 73.5 16710 51 230/1/50(
b
) 3 1.11 3526 1098 992
HBA99 95 25380 51 230/1/50(
b
) 4 1.63 4625 1098 992
(a): available with 230V/1ph/60Hz.
(b): available with 400V/3ph/60Hz
(c): vertical flow installation.
(d): at the following conditions: dT (condensing temp - outdoor temp) = 15°C; outdoor temperature 35°C; 0 m a.s.l.
Coupling of remote air condensers
Coupling of Condensers for HIFLEX single circuit
Model
External temperature
up to 30
o
C
External temperature
up to 35
o
C
External temperature
up to 40
o
C
External temperature
up to 46
o
C
Model
Standard Low noise Standard Low noise Standard Low noise Standard Low noise
4M U/O A HCA 07 HCA 07 HCA 07 HCA 07 HCA 07 HCA 10 HCA 14 HCA 14
4S/P U/O A HCA 07 HCA 07 HCA 07 HCA 07 HCA 07 HCA 10 HCA 14 HCA 14
4L/G U/O A HCA 07 HCA 10 HCA 10 HCA 10 HCA 10 HCA 14 HCA 14 HCA 14
6S/P U/O A HCA 10 HCA 10 HCA 10 HCA 14 HCA 14 HCA 14 HCA 14 HCA 14
6L/G U/O A HCA 10 HCA 14 HCA 14 HCA 14 HCA 14 HCA 24 HCA 24 HCA 24
8S/P U/O A HCA 14 HCA 14 HCA 14 HCA 17 HCA 17 HCA 24 HCA 24 HCA 29
8L/G U/O A/D HCA 14 HCA 14 HCA 14 HCA 24 HCA 24 HCA 24 HCA 29 HCA 42
