Coupling of Condensers for HIFLEX double circuit
Model
External temperature
up to 30
o
C
External temperature
up to 35
o
C
External temperature
up to 40
o
C
External temperature
up to 46
o
C
Model
Standard Low noise Standard Low noise Standard Low noise Standard Low noise
5S/P U/O A 2 x HCA07 2 x HCA07 2 x HCA07 2 x HCA07 2 x HCA07 2 x HCA10 2 x HCA14 2 x HCA14
5L/G U/O A 2 x HCA07 2 x HCA10 2 x HCA10 2 x HCA10 2 x HCA10 2 x HCA14 2 x HCA14
2 x HCA24
or
1 x HBA49
7S/P U/O A 2 x HCA10 2 x HCA10 2 x HCA10 2 x HCA14 2 x HCA14
2 x HCA17
or
1 x HBA33
2 x HCA24
or
1 x HBA49
2 x HCA24
or
1 x HBA49
7L/G U/O A 2 x HCA10 2 x HCA14 2 x HCA14 2 x HCA14 2 x HCA14
2 x HCA24
or
1 x HBA49
2 x HCA24
or
1 x HBA49
2 x HCA24
or
1 x HBA49
9S/P U/O A 2 x HCA14 2 x HCA14 2 x HCA14
2 x HCA17
or
1 x HBA33
2 x HCA17
or
1 x HBA33
2 x HCA24
or
1 x HBA49
2 x HCA24
or
1 x HBA49
2 x HCA29
9L/G U/O A/D 2 x HCA14 2 x HCA14 2 x HCA14
2 x HCA24
or
1 x HBA49
2 x HCA24
or
1 x HBA49
2 x HCA24
or
1 x HBA49
2 x HCA29
2 x HCA42
or
1 x HBA87
Coupling of Condensers for HIFLEX constant
Model
External temperature
up to 30
o
C
External temperature
up to 35
o
C
External temperature
up to 40
o
C
External temperature
up to 46
o
C
Model
Standard Low noise Standard Low noise Standard Low noise Standard Low noise
4S/P CA HCA 07 HCA 07 HCA 07 HCA 07 HCA 07 HCA 10 HCA 10 HCA 14
4L/G CA HCA 07 HCA 07 HCA 07 HCA 10 HCA 10 HCA 14 HCA 14 HCA 24
6S/P CA HCA 10 HCA 10 HCA 10 HCA 14 HCA 14 HCA 14 HCA 24 HCA 24
8S/P CA HCA 14 HCA 14 HCA 14 HCA 14 HCA 14 HCA 24 HCA 24 HCA 29
The coupling applies for a total equivalent distance of max. 30 m and in compliance with the instructions for the unit installation.
Max. geodetic height difference between condenser and unit: 3 m (if the condenser is placed underneath the ambient unit).
