Technical data and performances-water condensation -xxCW series, upward flow-60Hz
MODEL 4SCW 4LCW 6SCW 8SCW
power supply voltage V/ph/Hz
208-230/1/60 200-230/3/60 200-230/3/60 380/3/60
PERFORMANCES
(1)
air flow m
3
/s 0.38 0.53 0.64 0.99
available head Pa 0 50 50 50
fan absorbed power kW 0.4 1.0 0.5 1.1
fan absorbed current A 1.9 3.9 2.5 4.6
sound pressure level
(2)
dB(A) 49.4 51.7 54.7 50.9
condenser inlet water temperature: 15°C; condensation temperature: 40°C
total cooling capacity kW 6.3 9.2 11.9 15.5
sensible cooling capacity kW 5.0 7.2 9.6 13.2
full absorbed power (fan and compressor) kW 1.9 3.1 3.2 4.2
compressor absorbed power kW 1.5 2.2 2.7 3.2
compressor absorbed current A 5.9 6.1 7.3 4.1
SHR (Sensible Heat Ratio) - 0.80 0.79 0.81 0.85
EER (Energy Efficiency Ratio) - 3.26 2.93 3.72 3.70
water flow l/s 0.06 0.09 0.11 0.15
water pressure drop kPa 1 2 1 2
condenser inlet water temperature: 30°C; condensation temperature: 45°C
total cooling capacity kW 6.1 8.9 11.5 15.1
sensible cooling capacity kW 4.9 7.1 9.5 13.1
full absorbed power (fan and compressor) kW 2.1 3.4 3.5 4.6
compressor absorbed power kW 1.7 2.5 3.0 3.5
compressor absorbed current A 6.5 6.6 7.9 4.5
SHR (Sensible Heat Ratio) - 0.82 0.80 0.82 0.86
EER (Energy Efficiency Ratio) - 2.90 2.61 3.31 3.31
water flow l/s 0.13 0.22 0.24 0.35
water pressure drop kPa 4 12 5 11
FANS
quantity no. 1 1 1 1
type - dd 9/9 dd 9/9 dd 10/10 dd 12/12
speed no. 3 3 3 3
nominal power kW 0.245 0.420 0.500 0.736
poles no. 6 4 6 6
COMPRESSOR
quantity/type 1/scroll
nominal power for each compressor HP 1.90 2.50 3.25 4.00
refrigerant R22 R22 R22 R22
EVAPORATING COIL
pipes/fins copper/aluminium
copper/treated
aluminium
fins for inch/rows no. 12/3 12/3 12/4 12/5
front surface m
2
0.33 0.33 0.33 0.50
position/quantity inclined/1
CONDENSER
quantity/type - 1/plate
water connections inch ½" BSP
DIMENSIONS
length mm 750 750 750 750
depth mm 450 450 600 750
height mm 1950 1950 1950 1950
plan surface m
2
0.34 0.34 0.45 0.56
WEIGHTS
net kg
gross kg
1 ON THE FOLLOWING STANDARD CONDITIONS: standard supply [voltage 10%]; room conditions 24°C bs; 50% R.H. (17°C bu)
2 Measured in the front part at 1 m height, 2 m distance, referred to free field, with working fans and compressor.
ATTENTION: the refrigerating outputs are meant after deduction of the heat taken from the fans, which must thus be added to the room load. The EER
refers only to the room unit. The unit air flow refers in standard configuration with clean class filter G3.
