Hiflex
75-D- Version
English
Technical data and performances-dualfluid - air condensation - xxU/OD series -50Hz
MODEL 8GUD 8GOD 8LUD 8LOD
power supply voltage V/ph/Hz 400/3/50 400/3/50 400/3/50 400/3/50
PERFORMANCES
air flow m
3
/s 1.22 1.05 1.22 1.05
available head Pa 20 50 20 50
fan absorbed power kW 1.1 1.0 1.1 1.0
fan absorbed current A 5.0 4.5 5.0 4.5
PERFORMANCES WITH MECHANICAL COOLING
(1)
total cooling capacity kW 15.6 15.1 14.4 13.7
sensible cooling capacity kW 13.5 12.5 12.9 11.6
total absorbed power (fan and compressor) kW 4.9 4.8 4.7 4.6
compressor absorbed power kW 3.8 3.8 3.6 3.6
compressor absorbed current A 7.6 7.6 7.3 7.3
SHR (Sensible Heat Ratio) - 0.87 0.83 0.90 0.85
SPL (Sound Pressure Level) at 2m, f.f.
(2)
dB(A) 52.1 54.8 52.1 54.8
EER (Energy Efficiency Ratio) - 3.18 3.15 3.06 2.98
PERFORMANCES IN DUALFLUID MODE
total cooling capacity kW 17.8 13.2 17.8 13.2
sensible cooling capacity kW 16.5 11.8 16.5 11.8
inlet/outlet water temperature °C 7/12 7/12 7/12 7/12
water flow l/s 0.850 0.630 0.850 0.630
unit pressure drop - water side kPa 29 17 29 17
SPL (Sound Pressure Level) at 2m, f.f.
(3)
dB(A) 51.6 54.5 51.6 54.5
FANS
quantity n. 1 1 1 1
type - dd 12/12 dd 12/12 dd 12/12 dd 12/12
speed n. 3 3 3 3
nominal power kW 0.736 0.736 0.736 0.736
poles kW 6 6 6 6
COMPRESSOR
quantity/type n. 1/scroll 1/scroll
nominal power for each compressor HP 5.0 5.0 5.0 5.0
refrigerant - R407C R407C R22 R22
EVAPORATING COIL
quantity n. 1 1 1 1
pipes/fins - copper/treated aluminium copper/treated aluminium
fins per inch/rows - 12/5 12/5 12/5 12/5
front surface m
2
0.50 0.50 0.50 0.50
position - inclined inclined
REFRIGERANT CONNECTIONS
gas line (pipe to be welden, o.d.) mm 16 16 16 16
liquid line (pipe to be welden, o.d.) mm 14 14 16 16
recommemded diameter for refrigerant lines to the condens
er (o.d.) Gas - Liquid
mm 16-16 16-16 16-16 16-16
DIMENSIONS
length mm 750 750 750 750
depth mm 750 750 750 750
height mm 1950 1950 1950 1950
plan surface m
2
0.56 0.56 0.56 0.56
WEIGHTS
net kg 305 305 305 305
gross kg 315 315 315 315
AT THE FOLLOWING STANDARD CONDITIONS:
1 standard supply [voltage 10%]; ambient conditions 24C bs; 50% R.H.(17C bu); condensation temperature: 45C
2 Measured at 1 m height and 2 m front distance, in free field, with working fans and compressor.
3 Measured at 1 m height and 2 m front distance, in free field, with working fans only.
The cooling capacities are meant after deduction of the heat taken from the fans. Therefore the heat must be added to the ambient load. EER refers
to the ambient unit only. The air flow of the units refers to the standard configuration with filter of the G3 class. The standard diameters of the pipes
only apply for lengths - between the air conditioner and the condensing unit - up to 30 equivalent m.
