Technical data and performances-dualfluid - air condensation - xxU/OD series -50Hz
MODEL 9GUD 9GOD 9LUD 9LOD
power supply voltage V/ph/Hz 400/3/50 400/3/50 400/3/50 400/3/50
PERFORMANCES
air flow m
3
/s 2.44 2.10 2.45 2.10
available head Pa 20 50 20 50
fans absorbed power kW 2.2 2.0 2.2 2.0
each fan absorbed current A 5.0 4.5 5.0 4.5
PERFORMANCES WITH MECHANICAL COOLING
(1)
total cooling capacity kW 31.2 30.2 28.8 27.4
sensible cooling capacity kW 27.0 25.0 25.8 23.2
total absorbed power (fans and compressors) kW 9.8 9.6 9.4 9.2
compressors absorbed power kW 7.6 7.6 7.2 7.2
each compressors absorbed current A 7.6 7.6 7.3 7.3
SHR (Sensible Heat Ratio) - 0.87 0.83 0.90 0.85
SPL (Sound Pressure Level) at 2m, f.f.
(2)
dB(A) 55.1 57.8 55.1 57.8
EER (Energy Efficiency Ratio) - 3.18 3.15 3.06 2.98
PERFORMANCES IN DUALFLUID MODE
total cooling capacity kW 35.6 26.4 35.6 26.4
sensible cooling capacity kW 33.0 23.6 33.0 23.6
inlet/outlet water temperature °C 7/12 7/12 7/12 7/12
water flow l/s 1.70 1.26 1.70 1.26
unit pressure drop - water side kPa 29 17 29 17
SPL (Sound Pressure Level) at 2m, f.f.
(3)
dB(A) 54.6 57.5 54.6 57.5
FANS
quantity n. 2 2 2 2
type - dd 12/12 dd 12/12 dd 12/12 dd 12/12
speed n. 3 3 3 3
nominal power kW 0.736 0.736 0.736 0.736
poles kW 6 6 6 6
COMPRESSOR
quantity/type n. 2/scroll 2/scroll
nominal power for each compressor HP 5.0 5.0 5.0 5.0
refrigerant - R407C R407C R22 R22
EVAPORATING COIL
quantity n. 2 2 2 2
pipes/fins - copper/treated aluminium copper/treated aluminium
fins per inch/rows - 12/5 12/5 12/5 12/5
front surface single coil m
2
0.50 0.50 0.50 0.50
position - inclined inclined
REFRIGERANT CONNECTIONS
gas line (pipe to be welden, o.d.) mm 16 16 16 16
liquid line (pipe to be welden, o.d.) mm 14 14 16 16
recommemded diameter for refrigerant lines to the condens
er (o.d.) Gas - Liquid
mm 16-16 16-16 16-16 16-16
DIMENSIONS
length mm 1490 1490 1490 1490
depth mm 750 750 750 750
height mm 1950 1950 1950 1950
plan surface m
2
1.12 1.12 1.12 1.12
WEIGHTS
net kg 595 595 595 595
gross kg 615 615 615 615
AT THE FOLLOWING STANDARD CONDITIONS:
1 standard supply [voltage 10%]; ambient conditions 24C bs; 50% R.H.(17C bu); condensation temperature: 45C
2 Measured at 1 m height and 2 m front distance, in free field, with working fans and compressor.
3 Measured at 1 m height and 2 m front distance, in free field, with working fans only.
The cooling capacities are meant after deduction of the heat taken from the fans. Therefore the heat must be added to the ambient load. EER refers
to the ambient unit only. The air flow of the units refers to the standard configuration with filter of the G3 class. The standard diameters of the pipes
only apply for lengths - between the air conditioner and the condensing unit - up to 30 equivalent m.
