Liebert Hiflex - Page 81

Hiflex
77-D- Version
English
Technical data and performances - dualfluid-air condensation - xxU/OD series -60Hz
MODEL 8GUD 8GOD 8LUD 8LOD
power supply voltage V/ph/Hz
380/3/60 380/3/60 380/3/60 380/3/60
PERFORMANCES
air flow m
3
/s
1.33 1.22 1.33 1.22
available head Pa
20 50 20 50
fan absorbed power kW
1.5 1.4 1.5 1.4
fan absorbed current A
6.6 5.8 6.6 5.8
PERFORMANCES WITH MECHANICAL COOLING
(1)
total cooling capacity kW
18.3 17.8 16.8 16.1
sensible cooling capacity kW
15.0 14.4 14.4 13.3
total absorbed power (fan and compressor) kW
6.1 6.0 5.9 5.8
compressor absorbed power kW
4.6 4.6 4.4 4.4
compressor absorbed current A
7.6 7.6 7.3 7.2
SHR (Sensible Heat Ratio) -
0.82 0.81 0.86 0.83
SPL (Sound Pressure Level) at 2m, f.f.
(2)
dB(A)
52.6 55.4 52.6 55.4
EER (Energy Efficiency Ratio) -
3.01 2.97 2.85 2.76
PERFORMANCES IN DUALFLUID MODE
total cooling capacity kW
19.1 14.7 19.1 14.7
sensible cooling capacity kW
17.6 13.1 17.6 13.1
inlet/outlet water temperature °C
7/12 7/12 7/12 7/12
water flow l/s
0.908 0.701 0.908 0.701
unit pressure drop - water side kPa
32 21 32 21
SPL (Sound Pressure Level) at 2m, f.f.
(3)
dB(A)
52.1 55.0 52.1 55.0
FANS
quantity no.
1 1 1 1
type -
dd 12/12 dd 12/12 dd 12/12 dd 12/12
speed no.
3 3 3 3
nominal power kW
0.736 0.736 0.736 0.736
poles kW
6 6 6 6
COMPRESSORS
quantity/type no.
1/scroll 1/scroll
nominal power for each compressor HP
5.9 5.9 5.0 5.0
refrigerant -
R407C R407C R22 R22
EVAPORATING COIL
quantity no.
1 1 1 1
pipes/fins -
copper/treated aluminium copper/treated aluminium
fins per inch/rows -
12/5 12/5 12/5 12/5
front surface m
2
0.50 0.50 0.50 0.50
position -
inclined inclined
REFRIGERANT CONNECTIONS
gas line (pipe to be welden, o.d.) mm 16 16 16 16
liquid line (pipe to be welden, o.d.) mm 14 14 16 16
recommemded diameter for refrigerant lines to the condens
er (o.d.) Gas - Liquid
mm 16-16 16-16 16-16 16-16
DIMENSIONS
length mm
750 750 750 750
depth mm
750 750 750 750
height mm
1950 1950 1950 1950
plan surface m
2
0.56 0.56 0.56 0.56
WEIGHTS
net kg
305 305 305 305
gross kg
315 315 315 315
AT THE FOLLOWING STANDARD CONDITIONS:
1 standard supply [voltage  10%]; ambient conditions 24C bs; 50% R.H.(17C bu); condensation temperature: 45C
2 Measured at 1 m height and 2 m front distance, in free field, with working fans and compressor.
3 Measured at 1 m height and 2 m front distance, in free field, with working fans only.
The cooling capacities are meant after deduction of the heat taken from the fans. Therefore the heat must be added to the ambient load. EER refers
to the ambient unit only. The air flow of the units refers to the standard configuration with filter of the G3 class. The standard diameters of the pipes
only apply for lengths - between the air conditioner and the condensing unit - up to 30 equivalent m.
