Hiflex
84 -F- Version
English
Technical data and performances - freecooler - xxU/OF series - 50Hz
MODEL 9GUF 9GOF 9LUF 9LOF
power supply voltage V/ph/Hz 400/3/50 400/3/50 400/3/50 400/3/50
PERFORMANCES
air flow m
3
/s 2.45 2.10 2.45 2.10
available head Pa 20 50 20 50
fans absorbed power kW 2.3 2.0 2.3 2.0
each fan absorbed current A 5.0 4.5 5.0 4.5
glycol percentage % 30.0 30.0 30.0 30.0
PERFORMANCES WITH MECHANICAL COOLING
(1)
total cooling capacity kW 28.2 27.9 27.2 26.7
sensible cooling capacity kW 26.0 24.3 24.7 23.3
full absorbed power (fans and compressors) kW 11.7 11.4 11.2 10.8
compressors absorbed power kW 9.4 9.3 8.9 8.8
each compressors absorbed current A 8.5 8.5 8.1 8.1
SHR (Sensible Heat Ratio) - 0.92 0.87 0.91 0.87
EER (Sensible Heat Ratio) - 2.42 2.45 2.43 2.46
mixture inlet temperature °C 41.9 41.8 41.6 41.5
mixture flowrate l/s 1.28 1.28 1.28 1.28
mixture pressure drop condensers kPa 38 38 38 38
mixture pressure drop pressostatic valve kPa 52 52 52 52
SPL (Sound Pressure Level) (2) dB(A) 55.1 57.8 55.1 57.8
PERFORMANCES IN FREECOOLING MODE
total cooling capacity kW 23.5 22.0 23.5 22.0
sensible cooling capacity kW 23.5 22.0 23.5 22.0
mixture inlet temperature °C 7.0 7.0 7.0 7.0
mixture flowrate l/s 1.28 1.28 1.28 1.28
mixture pressure drop condensers kPa 29 28 29 28
SPL (Sound Pressure Level) (3) dB(A) 54.7 57.5 54.6 57.5
PERFORMANCES AT ZET MODE
(4)
mixture inlet temperature
Eintrittstemperatur MIX.
°C 5.0 5.2 6.2 6.5
ZET (Zero Energy Temperature) °C 0.4 0.2 1.1 1.7
mixture flowrate l/s 1.28 1.28 1.28 1.28
mixture pressure drop unit kPa 29 28 29 28
mixture pressure drop rad-cooler kPa 15 15 15 15
rad cooler ARN mod. DSM028 DSM028 DSM028 DSM028
FANS
quantity no. 2 2 2 2
type - dd 12/12 dd 12/12 dd 12/12 dd 12/12
speed n. 3 3 3 3
nominal power kW 0.736 0.736 0.736 0.736
poles no. 6 6 6 6
COMPRESSORS
quantity no. 2 2 2 2
type - scroll scroll
nominal power for each compressor HP 5.0 5.0 5.0 5.0
refrigerant - R407C R407C R22 R22
EVAPORATING COIL
quantity no. 2 2 2 2
pipes/fins - copper/treated aluminium copper/treated aluminium
fins per inch/rows - 12/5 12/5 12/5 12/5
front surface single coil m
2
0.50 0.50 0.50 0.50
position - inclined inclined
CONDENSERS
type - plate plate
quantity - 2 2 2 2
water connections inch ½ BSP ½ BSP ½ BSP ½ BSP
DIMENSIONS
length mm 1490 1490 1490 1490
depth mm 750 750 750 750
height mm 1950 1950 1950 1950
plan surface m
2
1.12 1.12 1.12 1.12
WEIGHTS
net kg 615 615 615 615
gross kg 635 635 635 635
AT THE FOLLOWING STANDARD CONDITIONS:
1 standard supply [voltage 10%]; ambient conditions 24C bs; 50% R.H.(17C bu); external temperature = 35°C
2 Measured at 1 m height and 2 m front distance, in free field, with working fans and compressor.
3 Measured at 1 m height and 2 m front distance, in free field, with working fans only.
4 ZET: Is the outdoor air temperature value ...
The cooling capacities are meant after deduction of the heat taken from the fans. Therefore the heat must be added to the ambient load. EER refers
to the ambient unit only. The air flow of the units refers to the standard configuration with filter of the G3 class. The standard diameters of the pipes
only apply for lengths - between the air conditioner and the condensing unit - up to 30 equivalent m.
