Liebert Hiflex - Page 89

Hiflex
85-F- Version
English
Technical data and performances - freecooller -xxU/OH series -60Hz
MODEL 8GUF 8GOF 8LUF 8LOF
power supply voltage V/ph/Hz 380/3/60 380/3/60 380/3/60 380/3/60
PERFORMANCES
air flow m
3
/s 1.33 1.22 1.33 1.22
available head Pa 20 50 20 50
fan absorbed power kW 1.5 1.4 1.5 1.4
each fan absorbed current A 6.6 5.8 6.6 5.8
glycol percentage % 30.0 30.0 30.0 30.0
PERFORMANCES WITH MECHANICAL COOLING
(1)
total cooling capacity kW 19.1 19.0 17.6 17.1
sensible cooling capacity kW 15.5 15.0 14.6 14.1
full absorbed power (fan and compressor) kW 6.0 5.9 5.9 5.8
compressor absorbed power kW 4.5 4.5 4.4 4.4
each compressors absorbed current A 7.5 7.5 8.7 8.7
SHR (Sensible Heat Ratio) - 0.89 0.83 0.83 0.82
EER (Sensible Heat Ratio) - 3.16 3.20 2.99 2.98
mixture inlet temperature °C 3.0 30 30 30
mixture flowrate l/s 0.615 0.607 0.542 0.534
mixture pressure drop condenser kPa 36 35 28 27
mixture pressure drop pressostatic valve kPa 48 47 38 36
SPL (Sound Pressure Level) (2) dB(A) 52.6 55.4 52.6 55.4
PERFORMANCES IN FREECOOLING MODE
total cooling capacity kW 12.0 11.6 11.2 10.8
sensible cooling capacity kW 12.0 11.6 11.2 10.8
mixture inlet temperature °C 7.0 7.0 7.0 7.0
mixture flowrate l/s 0.625 0.607 0.545 0.534
mixture pressure drop condenser kPa 19 18 15 15
SPL (Sound Pressure Level) (3) dB(A) 52.1 55.0 52.1 55.0
FANS
quantity n. 1 1 1 1
type - dd 12/12 dd 12/12 dd 12/12 dd 12/12
speed n. 3 3 3 3
nominal power kW 0.736 0.736 0.736 0.736
poles n. 6 6 6 6
COMPRESSOR
quantity n. 1 1 1 1
type - scroll scroll
nominal power for each compressor HP 5.0 5.9 5.0 5.0
refrigerant - R407C R407C R22 R22
EVAPORATING COIL
quantity n. 1 1 1 1
pipes/fins - copper/treated aluminium copper/treated aluminium
fins per inch/rows - 12/5 12/5 12/5 12/5
front surface m
2
0.50 0.50 0.50 0.50
position - inclined inclined
CONDENSER
type - plate plate
quantity - 1 1 1 1
water connections inch ½ BSP ½ BSP ½ BSP ½ BSP
DIMENSIONS
length mm 750 750 750 750
depth mm 750 750 750 750
height mm 1950 1950 1950 1950
plan surface m
2
0.56 0.56 0.56 0.56
WEIGHTS
net kg 310 310 310 310
gross kg 320 320 320 320
AT THE FOLLOWING STANDARD CONDITIONS:
1 standard supply [voltage  10%]; ambient conditions 24C bs; 50% R.H.(17C bu); external temperature = 35°C
2 Measured at 1 m height and 2 m front distance, in free field, with working fans and compressor.
3 Measured at 1 m height and 2 m front distance, in free field, with working fans only.
The cooling capacities are meant after deduction of the heat taken from the fans. Therefore the heat must be added to the ambient load. EER refers
to the ambient unit only. The air flow of the units refers to the standard configuration with filter of the G3 class. The standard diameters of the pipes
only apply for lengths - between the air conditioner and the condensing unit - up to 30 equivalent m.
