Hiflex
86 -F- Version
English
Technical data and performances - freecooller -xxU/OH series -60Hz
MODEL 9GUF 9GOF 9LUF 9LOF
power supply voltage V/ph/Hz 380/3/60 380/3/60 380/3/60 380/3/60
PERFORMANCES
air flow m
3
/s 2.66 2.44 2.66 2.44
available head Pa 20 50 20 50
fans absorbed power kW 3.0 2.8 3.0 2.8
fans absorbed current A 6.6 5.8 6.6 5.8
glycol percentage % 30.0 30.0 30.0 30.0
PERFORMANCES WITH MECHANICAL COOLING
(1)
total cooling capacity kW 37.9 37.5 35.5 34.4
sensible cooling capacity kW 30.7 29.7 29.1 27.9
full absorbed power (fans and compressors) kW 12.1 11.8 11.8 11.5
compressors absorbed power kW 9.1 9.1 8.8 8.7
each compressors absorbed current A 7.5 7.5 8.8 8.8
SHR (Sensible Heat Ratio) - 0.83 0.84 0.81 0.82
EER (Sensible Heat Ratio) - 3.13 3.19 3.01 3.00
mixture inlet temperature °C 30 30 30 30
mixture flowrate l/s 1.233 1.211 1.100 1.1074
mixture pressure drop condensers kPa 36 35 29 27
mixture pressure drop pressostatic valve kPa 49 47 39 37
SPL (Sound Pressure Level) (2) dB(A) 55.6 58.4 55.6 58.4
PERFORMANCES IN FREECOOLING MODE
total cooling capacity kW 23.8 22.8 22.3 21.2
sensible cooling capacity kW 23.8 22.8 22.3 21.2
mixture inlet temperature °C 7.0 7.0 7.0 7.0
mixture flowrate l/s 1.233 1.211 1.100 1.074
mixture pressure drop condensers kPa 27 26 22 22
SPL (Sound Pressure Level) (3) dB(A) 55.1 58.0 55.1 58.0
FANS
quantity n. 2 2 2 2
type - dd 12/12 dd 12/12 dd 12/12 dd 12/12
speed n. 3 3 3 3
nominal power kW 0.736 0.736 0.736 0.736
poles n. 6 6 6 6
COMPRESSORS
quantity n. 2 2 2 2
type - scroll scroll
nominal power for each compressor HP 5.0 5.9 5.0 5.0
refrigerant - R407C R407C R22 R22
EVAPORATING COIL
quantity n. 2 2 2 2
pipes/fins - copper/treated aluminium copper/treated aluminium
fins per inch/rows - 12/5 12/5 12/5 12/5
front surface single coil m
2
0.50 0.50 0.50 0.50
position - inclined inclined
CONDENSERS
type - plate plate
quantity - 2 2 2 2
water connections inch ½ BSP ½ BSP ½ BSP ½ BSP
DIMENSIONS
length mm 1490 1490 1490 1490
depth mm 750 750 750 750
height mm 1950 1950 1950 1950
plan surface m
2
1.12 1.12 1.12 1.12
WEIGHTS
net kg 615 615 615 615
gross kg 635 635 635 635
AT THE FOLLOWING STANDARD CONDITIONS:
1 standard supply [voltage 10%]; ambient conditions 24C bs; 50% R.H.(17C bu); external temperature = 35°C
2 Measured at 1 m height and 2 m front distance, in free field, with working fans and compressor.
3 Measured at 1 m height and 2 m front distance, in free field, with working fans only.
The cooling capacities are meant after deduction of the heat taken from the fans. Therefore the heat must be added to the ambient load. EER refers
to the ambient unit only. The air flow of the units refers to the standard configuration with filter of the G3 class. The standard diameters of the pipes
only apply for lengths - between the air conditioner and the condensing unit - up to 30 equivalent m.
