HIMOD−C
Fig. 5 − Chilled water connections
Himod C
over
A
B
BA
55−65−80−85
27−45
BA
A
B
150
150
220
220
300
300
160 / 200
90 (80−85 C)
170 (55−65 C)
Left side view
(SX)
Left side view
(SX)
Frontal view
Frontal view
POS
CONNECTION
DIMENSION
POS
.
CONNECTION
27C 45−55C 65−80−85C
A Chilled water inlet 1 " female 1 ¼" female 1 ½" female
B Chilled water outlet 1 " female 1 ¼" female 1 ½" female
