HIMOD−C
Fig. 6 − Auxiliary water connections
Himod C
under/over
Under single / double
Over single / double
155
145
80
105
215
105
170
105
170
590
A
B
C
D
E
D
E
E
D
D
E
E
D A
B
C
E
D
E
D A
B
C
27−45−55−65
80−85
27−45−55−65 80−85
27−45 55−65−80−85
90
27−45
55−65−80−85
27−45
Left side view
(SX)
Left side view
(SX)
Frontal view
Frontal view
Frontal view
A
B
C
55−65−80−85
POS.
CONNECTION DIMENSION
A HUMIDAIR water supply (optional) ½" G male
B HUMIDAIR water drain (optional)
 22 mm female
C Condensate drain
 20 mm female
D/E (small) Hot water inlet/outlet (optional)
 18 x 1 mm
D/E (big) Hot water inlet/outlet (optional)
 22 x 1 mm
