HIMOD−C
Fig. 7 − Auxiliary water connections
Himod C
under
B
A
90−10
12−14
C
D
E
90 490 85
135105
D
E
B
A
C
67
B
A
C
D
E
90 480 85
135105
D
E
B
A
C
67
Left side view
(SX)
Left side view
(SX)
Frontal view
Frontal view
POS.
CONNECTION DIMENSION
A HUMIDAIR water supply (optional) ½" G male
B HUMIDAIR water drain (optional)
 22 mm female
C Condensate drain
 20 mm female
D/E Hot water inlet/outlet (optional)
 22 x 1 mm
