10.0 PARTS
Table 19 Refrigeration system parts, 1.5 and 2 ton units
Figure
No.
Part Name/
Description Part #
1.5 Ton 2 Ton
ET017S ET018P ET023S ET023M ET024P ET024Y ET024A
220-240V
1Ph 50Hz
208-230V
1Ph 60Hz
220-240V
1Ph 50Hz
380-415V
3Ph 50Hz
208-230V
1Ph 60Hz
208-230V
3Ph 60Hz
460V
3Ph 60Hz
Run capacitor, scroll comp
7-7 Cap. 30μF, 370V 1A19537P1 1 N/A N/A N/A
7-7 Cap. 40μF, 370V 1A19538P1 1 1 N/A 1 N/A N/A
Compressors, scroll
7-6 Comp. 220/240-1 156204P1 1
7-6 Comp. 200/230-1 159146P1 1
7-6 Comp. 220/240-1 138493P2 1
7-6 Comp. 380/460-3 148324P2 1
7-6 Comp. 200/230-1 159145P1 1
7-6 Comp. 208/230-3 159148P1 1
7-6 Comp. 380/460-3 159148P2 1
Pressure switches
High pressure - 400 psi 159482P1 1 1 1 1 1 1 1
Fan cycle switch - 170 psi 159483P1 Optional feature - quantity 1 (as required)
Low pressure - 35 psi 159484P1 Optional feature - quantity 1 (as required)
Adj Pr Sw for Adj FCC P67-0110 Optional feature - quantity 1 (as required)
Filter drier 127185P1 1 1 1 1 1 1 1
7-10 Condenser coil-1.5/3T 159118P1 1 1 1 1 1 1 1
9-1 Evaporator coil-1.5/2T 159200P1 1 1 1 1 1 1 1
9-1 Thermal expansion valve-1.5T 1C19507P3 1 1
9-1 Thermal expansion valve-2T 1C19507P1 1 1 1 1 1
Crankcase heaters
7-9 Strap style 240V recips 159202P1 1 1 1 1 1
7-9 Strap style 480V recips 159202P2 1 1
Retainer plug 159136P1 1 1 1 1 1 1 1
14-1 Soft start kit 1C19540P1 Optional feature - quantity 1 (as required)
