Liebert InteleCool 2 User Manual

Parts
Liebert
®
InteleCool
®
239
Table 24 Electric panel parts, 3-ton units
Figure
No.
Part Name /
Description Part #
3 Ton
ET035S ET035N ET035M ET036P ET036Y ET036A
220-240V
1Ph 50Hz
200-240V
3Ph 50Hz
380-415V
3Ph 50Hz
208-230V
1Ph 60Hz
208-230V
3Ph 60Hz 3
460V
3Ph 60Hz
10-3 Transformer 208/230V 159463P1 1 1 1 1
10-3 Transformer 360/460V 159463P2 1 1
Circuit breakers
10-1 No heat 138457P1 147957P5 147957P8 138457P8 147957P5 147957P8
10-1 5 kW heat 138457P1 147957P5 147957P8 138457P8 147957P5 147957P8
10-1 10 kW heat 138457P2 147957P10 147957P1 138457P2 147957P10 147957P1
10-1 15 kW heat 138457P2 147957P3 147957P2 138457P2 147957P3 147957P11
10-1A Heater breaker 138457P5 N/A N/A 138457P5 N/A N/A
Circuit breakers - scrolls
10-1 No heat 138457P9 147957P9 147957P8 138457P1 147957P5 147957P8
10-1 5 kW heat 138457P9 147957P9 147957P8 138457P1 147957P5 147957P8
10-1 10 kW heat 138457P2 147957P10 147957P1 138457P2 147957P10 147957P1
10-1 15 kW heat 138457P2 147957P3 147957P2 138457P2 147957P3 147957P11
10-1A Heater breaker 138457P5 N/A N/A 138457P5 N/A N/A
Contactor, compressor
10-4 2 pole E-011B 1 1
10-4 3 pole 124501P1 1 1
10-4 3 pole E-0110 1 1
Contactor, heater, 5 kW
10-9 2 pole E-013A 1 1
10-9 3 pole 124501P1 1 1 1 1
Contactor, heater, 10 kW
10-9 2 pole E-011C 1 1
10-9 3 pole 124501P1 1 1
10-
9 3 pole E-0110 1 1
Contactor, heater, 15 kW
10-15 2 pole E-013A 1 1
10-9 2 pole E-011C 1 1
10-9 3 pole E-0110 1 1
10-9 3 pole E-009F 1 1
10-6 Contactor evaporator fan E-0130 1 1 1 1
10-6 Contactor evaporator fan E-013A 1 1
10-7 Contactor, condenser fan E-013A 1 1
10-8 Time delay relay, anticycle 148089P1 1 1 1 1 1 1
10-16 Heater interlock relay E03-0170 1 1
10-10 Terminal strip, 10 position 159468P1 1 1 1 1 1 1
Wall thermostat, 1 stage 138968P1 1 1 1 1 1 1
Thermostat base 138940P1 1 1 1 1 1 1
Optional features
10-13 Time delay relay, LP bypass 138491P1 Optional feature - quantity 1 (as required)
10-12 Economizer relay E03-0170 Optional feature - quantity 1 (as required)
10-11 Lockout relay E-0130 Optional feature - quantity 1 (as required)
Common alarm assembly
13-1 Air flow switch B02-0190 Optional feature - quantity 1 (as required)
13-2 T/D relay E-3530 Optional feature - quantity 1 (as required)
13-3 Relay R1 E03-0170 Optional feature - quantity 1 (as required)
13-4 Relay R2 E03-0170 Optional feature - quantity 1 (as required)
13-5 Thermostat E-0230 Optional feature - quantity 1 (as required)
