Liebert InteleCool 2 User Manual

Parts
Liebert
®
InteleCool
®
245
Table 30 Motor parts, heater, Economizer, 5-ton units
Figure
No.
Part Name/
Description Part #
5 Ton
ET059N
ET359N
ET059M
ET359M
ET060P
ET360P
ET060Y
ET360Y
ET060A
ET360Y
200-230V
3Ph 50Hz
380-415V
3Ph 50Hz
208-230V
1Ph 60Hz
208-230V
3Ph 60
460V
3Ph 60Hz
Condenser fan motors
Standard
7-1 Motor 1/3 Hp, 200/240V (std) 159266P1 1 1 1
7-1 Motor 1/3 Hp, 380/460V (std) 159266P2 1 1
7-2 Fan prop, 4 blade, 24", 28-deg 159241P2 1 1 1 1 1
High ambient option
7-1 1/2 Hp, 200/240V (high amb) 159265P1 1 1 1
7-1 1/2 Hp, 380/460V (high amb) 159265P2 1 1
7-2 Fan prop, 4 blade, 24", 24-deg 159241P1 1 1 1 1 1
7-8 Capacitor, run 10μF, 370V B03-0030 1 1 1 1 1
7-4 Motor mount 159175P1 1 1 1 1 1
Evaporator fan motors
8-11 Motor 1/2 Hp dual 200/230V 159267P1 1 1 1
8-11 Motor 1/2 Hp dual 380/460V 159267P2 1 1
8-2 Blower, CW 159254P2 1 1 1 1 1
8-1 Blower, CW 159254P1 1 1 1 1 1
8-3 Capacitor, run 10μF, 370V B03-0030 1 1 1 1 1
8-8 Motor mount 159263P1 1 1 1 1 1
8-9 Mount bolt 100061 1 1 1 1 1
8-10 Mount nut S-3380 1 1 1 1 1
8-4 Grommet washer 127843P1 6 6 6 6 6
8-5 Screw 147993P1 6 6 6 6 6
8-6 Grommet tube 127843P2 6 6 6 6 6
8-7 Spacing sleeve 127843P3 6 6 6 6 6
Heaters - optional
11-1 Heater element, 5kW, 240V 159170P1 1 1 1 1
11-1 Heater element, 5kW, 277V 159170P2 1
11-1 Heater element, 10kW, 240V 159170P3 1 1 1 1
11-1 Heater element, 10kW, 277V 159170P4 1
11-1 Heater element, 15kW, 240V 159170P5 1 1 1 1
11-1 Heater element, 15kW, 277V 159170P6 1
11-1 Fuse link, safety 147896P1 3 3 3 3 3
11-1 Therm switch, safety (5kW) R-013A 1 1 1 1 1
11-1 Therm switch, safety (10,15kW) R-013B 1 1 1 1 1
11-1 Jumper wire 146807G1 3 2 4 3 2
Economizer - optional
12-1 Actuator motor, spring return 159115P1 Optional feature - quantity 1 (as required)
12-2 Min position potentiometer 159471P1 Optional feature - quantity 1 (as required)
12-3 Enthalpy control 138401P1 Optional feature - quantity 1 (as required)
12-4 Mixed air sensor 159204P1 Optional feature - quantity 1 (as required)
12-5 Push rod 159137P1 Optional feature - quantity 1 (as required)
12-6 Linkage, ball type 129645P1 Optional feature - quantity 1 (as required)
12-7 Filter, 2" x 21" x 36.25" 138447P3 1 1 1 1 1
