SPECIFICATIONS
MODEL NUMBER GXT1500RT-120 GXT2000RT-120 GXT3000RT-120
MODEL RATING
VA/W
1500 / 1050 2000 / 1400 3000 / 2100
DIMENSIONS: in (mm)
Unit
W x D x H
7.0 x 19.3 x 16.9
(177 x 522 x 430)
7.0 x 19.3 x 16.9
(177 x 522 x 430)
7.0 x 19.3 x 16.9
(177 x 522 x 430)
Shipping
W x D x H
13.38 x 26.0 x
22.25
(340 x 660 x 565)
13.38 x 26.0 x 22.25
(340 x 660 x 565)
13.38 x 26.0 x
22.25
(340 x 660 x 565)
WEIGHT: kg (lbs)
Unit 60.9 (27.7) 80.9 (36.8) 85.9 (39.0)
Shipping 68.0 (30.9) 88.0 (40.0) 93.0 (42.3)
INPUT AC PARAMETERS
Voltage Range (typical) 120 VAC nominal; variable based upon output load
100% - 90% Loading 90-93 VAC to 134-138 VAC
90% - 70% Loading 80-83 VAC to 134-138 VAC
70% - 30% Loading 70-73 VAC to 134-138 VAC
30% - 0% Loading 60-63 VAC to 134-138 VAC
Frequency 48.1 - 51.9 Hz or 57.6 - 62.4 Hz; auto sensing
Input Power Cord 6 ft. detached, w/
NEMA 5-15 plug
6 ft. detached, w/
NEMA 5-20 plug
6 ft. detached, w/
NEMA L5-30 plug
OUTPUT AC PARAMETERS
Output Receptacles (8) NEMA 5-15R (6) NEMA 5-15R
(2) NEMA 5-20R
(6) NEMA 5-15R
(1) NEMA L5-30R
Voltage 100/110/120/127 (switch selectable) VAC; ±3%
Frequency 50 Hz or 60Hz
Waveform Sinewave
Main Mode Overload 200% for 8 cycles; 130% for 10 seconds with transfer to bypass
BATTERY PARAMETERS
Type Valve-regulated, nonspillable, lead acid
Qty. x Voltage x Rating 4 x 12V x7 or 7.2 AH 8 x 12V x 6.5 or 7.0
AH
8 x 12V x 7 or 7.2
AH
Batt. Mfg./ Part # CSB GP1270F2 or Panasonic LC-R127R2CH1
Back-up Time See Typical Battery Discharge Curves
Recharge Time 5 Hours to 95% capacity after full discharge into 100% load
ENVIROMENTAL
Operating Temperature +32° F to +104° F (0° C to +40° C)
Storage Temperature +5° F to +122 °F (-15° C to +50° C)
Relative Humidity 0% to 95%, non-condensing
Operating Elevation Up to 10,000 ft. (3000 m) at 40° C without derating
Storage Elevation 50,000 ft. (15.000 m) maximum
Audible Noise <50 dBA, at 1 meter
AGENCY
Safety UL 1778, c-UL Listed
RFI/EMI FCC Part 15, Subpart B, Class A
Immunity
IEEE 587 Category A
