related side effects (conductor overload, circuit breakers and machines, phase unbalances,
interferences in electronic units, RCCB trips, etc.).
The level of harmonics is usually measured with the total harmonic distortion rate (THD), which
is the ratio, usually as a %, of the RMS value of the harmonic content and the value of the fun-
damental component.
4.2.- MEASUREMENT PARAMETERS
The unit displays the following electrical parameters:
4�2�1� CONNECTION TYPE: 3U.3C
Table 3: Controller MASTER control VAR FAST measurement parameters (3U.3C connection)
Parameter Units Phases
L1-L2-L3
N
Total
III
Max
(1)
Min
(2)
Phase-neutral voltage V
   
Phase-phase voltage V
   
Current A
   
Leakage current mA
  
Frequency Hz
(L1)  
Active Power M/kW
   
Apparent Power M/kVA
   
Total Reactive Power M/kvar
   
Inductive Reactive Power M/kvarL
   
Capacitive Reactive Power M/kvarC
   
Power factor PF
   
Cos φ φ
   
Voltage THD % % THD V
 
Current THD % % THD A
 
Harmonic Breakdown - Voltage
(up to the 17th harmonic)
harm V
 
Harmonic Breakdown - Current
(up to the 17th harmonic)
harm A
 
Active energy M/kWh

Inductive Reactive Energy M/kvarLh

Capacitive Reactive Energy M/kvarCh

Apparent energy M/kVAh

Temperature ºC

No. of operations x1000

Total activated power %

(1)
Displays the maximum value.
(2)
Displays the minimum value.
25
Instruction Manual
Controller MASTER control VAR FAST
