Energy III generated Parameters
Active Energy III generated
(kWh or MWh)
Inductive Reactive Energy III generated
(kvarLh or MvarLh)
Capacitive Reactive Energy III generated
(kvarCh or MvarCh)
Apparent Energy III generated
(kVAh or MVAh)
Operations Parameters
No� of operations of stage C1 to C12
Three screens show the number of operations
of the 12 possible stages.
for more than 3 seconds: delete the no.
of operations.
This parameter should be associated with an alarm that is activated when the number of oper-
ations exceeds a pre-determined value (for example, 5000 operations) in order to perform the
maintenance of this stage.
There are thousands of operations, so the value displayed is in thousands of operations (which
is the reason for the k icon).
Active alarms Parameters
Active alarm code E01 to E017
(Table 9)
If there are more than 4 alarms, the
information is scrolled on the screen.
53
