C4,C4P / C8, C8P Installation Manual
10 11
Zone 1
24V Mag Lock Output, Voltage Input, with FAI
This zone shows a typical 24V Mag Lock application, using
a voltage input on the zone. The door will unlock upon an
FAI signal being received from the FPO Power Supply.
Jumper Positions: A-1
|
B-1
|
C-2
|
D-1
|
E-2
|
F-2
Zone 2
12V Mag Lock Output, NC Relay Contact Input, no FAI
This zone shows a typical 12V Mag Lock application, using
a NC relay contact as the input for the zone. The door will
remain locked during a fire alarm condition.
Jumper Positions: A-2
|
B-1
|
C-2
|
D-2
|
E-2
|
F-2
Zone 3
12V Door Strike Output, Open Collector (transistor) Input,
no FAI
This zone shows a typical 12V Door Strike application, us-
ing an open collector (transistor) input on the zone. The
door will remain locked during a fire alarm condition.
Jumper Positions: A-2
|
B-1
|
C-2
|
D-2
|
E-2
|
F-1
Zone 4
24V Door Strike Output,NO Relay Contact Input, with FAI
This zone shows a typical 24V Door Strike application, us-
ing a NO relay contact as the input for the zone. The door
will unlock upon an FAI signal being received from the FPO
Power Supply.
Jumper Positions: A-1
|
B-2
|
C-2
|
D-1
|
E-2
|
F-1
Zone 5
12V Reader Power, no control input, no FAI
This zone shows continuous 12V auxiliary power for pow-
ering a device such as a reader. Power will remain during a
fire alarm condition.
Jumper Positions: A-2
|
B-2
|
C-2
|
D-2
|
E-2
|
F-2
Zone 6
24V Aux Power, no control input, with FAI
This zone shows continuous 24V auxiliary power for pow-
ering devices such as door holders. Power will be removed
from the output upon an FAI signal being received from the
FPO power supply.
Jumper Positions: A-1
|
B-2
|
C-2
|
D-1
|
E-2
|
F-2
Zone 7
NO Relay Contact Output, Open Collector (transistor) In-
put, with FAI
This zone shows a NO relay contact output using an open
collector (transistor) input on the zone. The output relay
will close upon an FAI signal being received from the FPO
power supply.
Jumper Positions: A-2
|
B-1
|
C-1
|
D-1
|
E-1
|
F-1
Zone 8
NC Relay Contact Output, NC Relay Contact Input, with FAI
This zone shows a NC relay contact output slaving off of
a NC relay contact input. This application can be used to
protect the low-current integral relays in an access control
panel and instead use the higher current relays on the C8 to
control the locks.
Jumper Positions: A-1
|
B-1
|
C-1
|
D-1
|
E-1
|
F-2
C8/C8P Application Example - continued
