LifeSize Express 200 Installation Guide 17
Optional Peripherals
You can connect the following optional peripherals to enhance your LifeSize system:
Peripheral Usage
DVI-I In DVI-I port for connecting laptops for presentations or to share PC data. For
devices and PCs with VGA output, LifeSize includes a DVI-A to VGA
cable. An HDMI source can be used with an adapter. For more information
about supported resolutions and audio support, refer to the LifeSize Video
Communications Systems Administrator Guide.
Networker For use with LifeSize Networker.
Note: This port is also marked with the LifeSize Phone symbol and
can be used with either LifeSize Phone or LifeSize Networker.
Microphone in For use with a single or dual LifeSize MicPod configuration.
In a single LifeSize MicPod configuration, you can add a LifeSize MicPod
extension cable (15 meters, 49.2 feet) to the LifeSize MicPod.
In a dual LifeSize MicPod configuration, you use a combination of two
LifeSize MicPods, one splitter cable, and extension cables in large rooms
to create wider coverage of audio input. Refer to “Configuring Dual
LifeSize MicPods” on page 18.
Audio In (Line In) For use with an external line level audio input, in addition to the
LifeSize Phone or LifeSize MicPod.
Audio Out (Line Out) For use with external line level output speakers that are not built into
display 1 or with a headset (left plus right).
Warning: Excessive sound pressure from earphones and
headphones can cause hearing loss.
