10. PARTS LIST
No.
Description
Specification
QTY
No.
Description
Specification
QTY
A01
Base frame
1
C12
Handle bar foam
2
A02
Main frame
1
C13
Rubber pad
1
A03
Incline bracket
1
C14
Plastic bracket
1
A04
Console bracket
1
C15
Side rail
2
A05
Left upright tube
1
C16
Running belt
1
A06
Right upright tube
1
C17
Air cushion
2
A07
Motor bracket
1
C18
Side rail anti-slip pad
2
B01
Front roller
1
C19
Black cushion
4
B02
Back roller
1
C20
Blue cushion
2
B03
Air pressure cylinder
1
C21
Blue cushion
2
B04
Hand pulse
sheet iron 1
2
C22
Transport wheel
2
B05
Hand pulse
sheet iron 2
2
C23
Oval inner plug
2
B06
Transport wheel cover
4
C24
Motor belt
1
B07
Spring sheet
2
C25
Cone-shape cushion
1
B08
Left speaker net
1
C26
Flat foot pad
4
B09
Right speaker net
1
C27
Adjustable wheel
2
B10
Turning bush
4
C28
Wire protector
2
B11
Copper sheet
1
C29
Plastic pad
4
B12
Allen wrench
5mm
1
C30
Safety key bracket
1
B13
Spanner with screw driver
S=13,14,15
1
C31
Safety key
1
B14
Z shape board
2
C32
Transport wheel plug
2
B15
Safety block
1
C33
Motor top cover acrylic
1
C01
Console top cover
1
C34
Handle bar decoration ring
2
C02
Console middle top cover
1
C35
Handle bar left cover
1
C03
Console middle bottom
cover
1
C36
Handle bar right cover
1
C04
Hand pulse top cover
1
D01
Computer board
1
C05
Hand pulse bottom cover
1
D02
Control board
1
C06
Motor top cover
1
D03
Handle bar button board
1
C07
Motor bottom cover
1
D04
Top signal wire
900mm
1
C08
Left upright tube cover
1
D05
Middle signal wire
1100mm
1
C09
Right upright tube cover
1
D06
Bottom signal wire
800mm
1
C10
Left back end cover
1
D07
Shortcut top wire
350mm
1
C11
Right back end cover
1
D08
Shortcut bottom wire
750mm
1
