LifeSpan E2i - Hardware Included

23
Hardware Included
Item# Part Description Item# Part Description
1 Main Base 6 Console
2 Ramp Base 7 Right Arm Assembly
3 Base Connection Cover 8 Left Arm Assembly
4 Console Mast 9 Mid Arm Joint Covers
5 Base Top Cover
10A
10B
Lower Arm Joint Covers
Hardware Bag Contents
Item # Qty. Hardware
Description
N/A 2 13/17mm Wrench
N/A 1 6mm Allen Wrench
N/A 1 5mm Allen
Wrench w/Phillips
Screwdriver
N/A 1 4mm Allen Wrench
Pre-installed Hardware (not shown)
Item # Pre-Installed Hardware
17 M8 x 20L Bolt
18 M8 Washer
19 Console Mast Cover
20 M4 x 10L Screw
Assembling Your Elliptical
6mm Allen
Wrench
4mm Allen
Wrench
5mm Allen
Wrench w/
Phillips
13/17mm
Wrench (x2)
M8 x 45L
(x2)
M8 Nylock Nut
(x2)
M8 Washer
(x8)
M8 x 35L
(x2)
M4 x 10L Screw
(x6)
M8 x 20L Screw
(x4)
Item # Qty. Hardware
Description
11 2 M8 x 45L Bolt
12 2 M8 Nylock Nut
13 8 M8 Washer
14 2 M8 x 35L Bolt
15 6 M4 x 10L Screw
16 4 M8 x 20L Bolt
Item # Pre-Installed Hardware
21 M8 x 15L Bolt
22 M8 x 30L Bolt
23 M4 x 50L Screw
24 Wave Washer
25 M3.5 x 10L Screw
M8
Washer
M4x10L
Screw
M8x15L
Bolt
M8x30L
Bolt
M4x50L
Screw
M5 x 10L
Bolt
Wave
Washer
M3.5x10L
Screw
