Lifetime 60057 - Page 10

10
77”
FLOOR ASSEMBLY HARDWARE [BYC]
Hardware shown at actual size
BQC (x4)
Xv0AN(EAD3CREW
AHOX
Door Hinge Bushing
70 7/8”
54 3/8”
40”
43 1/4”
67 3/4”
78 3/8”
60057 METAL KIT [CNW]
Parts shown at 8% of actual size
AFG (x1)
Truss Brace
BYA (x1)
Left Angled Door Jamb
AFM (x4)
Wall Support Channel
BXX (x1)
Rear Wall Support Square Tube
AFE (x1)
Entry Header Bar
AFHX
4RUSS'UTTER#HANNEL
72 3/8”
BYB (x1)
Right Angled Door Jamb
75”
CHIX
Door Square Tube
PARTS IDENTIFIER
ADC (x1)
0HILLIPS"IT
CHHX
Door Hinge Tube
