Lifetime 60057 - LEFT DOOR ASSEMBLY; Left Door Assembly Hardware & Parts

34
AEE (x7)
&LAT7ASHER
BZB (x4)
Xv.YLON3PACER
BYS (x1)
Outer Door Handle
BYQX
Deadbolt Latch
BYPX
Deadbolt Latch Bracket
BYR (x1)
Inner Door Handle
LEFT DOOR ASSEMBLY
HARDWARE REQUIRED
HARDWARE BAG REQUIRED: BYJ
METAL PARTS REQUIRED
SEC
ADW (x5)
Xv0AN(EAD3CREW
BYZX
Xv0AN(EAD3CREW
Hardware shown at actual size
0ARTSSHOWNATOFACTUALSIZE
Part shown at 8% of actual size
BBH (x1)
1” Square End Cap
CHK (x1)
Xv3ELF$RILLING3ELF4APPING3CREW
CHH (x1)
Door Hinge Tube
77”
75”
CHI (x1)
Door Square Tube
ARA (x1)
1/8” Drill Bit
5
METAL PARTS KIT REQUIRED: CNW
