28
78 3/8”
67 3/4”
ADZ (x55)
1/4” x 5/8” Pan-Head Screw
ADV (x6)
1/4” x 1 1/8” Pan-Head Screw
WALL INSTALLATION
HARDWARE REQUIRED
METAL PARTS REQUIRED
PLASTIC PARTS REQUIRED
TOOLS REQUIRED
SEC
Phillips Screwdriver
Safety Glasses
Hardware shown at actual size
Parts shown at 8% of actual size
Parts shown at 4% of actual size
AHD (x4)
Wall Panel
AGL (x4)
Corner Wall Panel
AFM (x4)
Wall Panel Support Channel
BXX (x1)
Rear Wall Support Square Tube
*AIW Wood Block (x1) (Provided)
HARDWARE BAG REQUIRED: CNU
4
METAL PARTS KIT REQUIRED: CNW
SMALL PARTS BOX REQUIRED: CVX
