WALL INSTALLATION HARDWARE [CNU]
Hardware shown at actual size
PARTS IDENTIFIER
ADZ (x55)
1/4” x 5/8” Pan-Head Screw
ADV (x6)
1/4” x 1 1/8” Pan-Head Screw
TRUSS ASSEMBLY HARDWARE [BYD]
Hardware shown at actual size
Parts shown at 50% of actual size
0ARTSHOWNATOFACTUALSIZE
9 3/4”
ADYX
Xv0AN(EAD3CREW
BXU (x1)
Truss Connector A
ADH (x1)
1/4” Threaded Rod
BXV (x1)
Truss Connector B
BXW (x1)
Truss Connector Bracket
ADKX
#AP.UT
ADJX
1/4” Cap Nut
SHELF INSTALLATION HARDWARE
Hardware shown at actual size (*Unless noted otherwise)
30” Shelf Installation Hardware [BHH]
ADZ (x4)
1/4” x 5/8” Pan-Head Screw
ADZ (x14)
1/4” x 5/8” Pan-Head Screw
(Only 4 used)
*AIYX
10” Shelf Bracket
Corner Shelf Installation Hardware [BHI] x2
GABLE ASSEMBLY HARDWARE [BYF]
Hardware shown at actual size
ADZX
1/4” x 5/8” Pan-Head Screw
ADV (x6)
1/4” x 1 1/8” Pan-Head Screw
