Lifetime 90192 - Page 18

18
TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
ADS (x1)
Align the hole in the Top Pole (ALH) with the slot in the -IDDLE0OLE!,& and
slide the Top Pole over the Middle Pole. Insert a vXv3CREW!$3
through a $OMED#OUNTERSINK7ASHER#)( and the small hole in the Top Pole
and into the slot in the Middle Pole as shown.
SEC
1.3
ALH
!,&
Note: The 1/4” x 3/4” Screw should be fl ush with the Pole, but
will spin freely once installed. Do not jam the Poles together
until instructed.
!
ALH
!,&
ADS
CIH (x1)
CIH
