19
TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
Align the hole in the -IDDLE0OLE!,& with the slot in the Bottom Pole (ALE) and
slide the Middle Pole over the Bottom Pole. Insert a vXv3CREW!$3
through the small hole in the Middle Pole and into the slot in the Bottom
Pole using the hardware shown.
SEC

Note: The 1/4” x 3/4” Screw should be fl ush with the Pole, but
will spin freely once installed. Do not jam the Poles together
until instructed.
!
!,&
ALE
ADS (x1)
CIH (x1)
!,&
ALE
ADS
CIH
