TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
1/2”
(Not to scale)
ABK (x2)
!*7 (x2)
!/7 (x1)
(Not to scale)
Slide the #OMPRESSION3PRINGS!*7 onto the v5"OLT!/5, and
place the 3PRING2ETAINER0LATE!/7 over the Compression Springs.
Tighten the v.YLOCK&LANGE.UTS!"+ until the 2IM!,8 does not
wobble to complete this step.
SEC
3.6
Note: DO NOT COMPLETELY TIGHTEN THE 5/16” NYLOCK FLANGE NUTS IN
THIS STEP! Only tighten the Nuts until the Rim (ALX) does not wobble.
Tightening the Nuts will adjust the Rim tension.
!
ABK
!/7
!*7
AOU
!,8
